PUMP ZU4 VE42Q 1LCD230CE 8L RBAR

PUMP ZU4 VE42Q 1LCD230CE 8L RBAR

  • Model ZU4208TE-QR
  • Product Line Bolting Tools
  • Series ZU4T

a

Description

  • Features Z-Class high-efficiency pump design; higher oil flow and bypass pressure, cooler running and requires 18% less current draw than comparable pumps
  • Powerful 1,25 kW universal electric motor provides high power-toweight ratio and excellent low-voltage operating characteristics
  • High-strength, molded composite shroud protects motor and electrical components, while providing an ergonomic, non-conductive handle for easy transport
  • Roll Cage protects pump and provides greater pump stability
  • Low-voltage pendant provides additional safety for the operator
  • Pro Series:
  • LCD readout provides pressure and torque display and a number of diagnostic and readout capabilities never before off ered on a portable electric pump
  • Auto cycle feature provides continuous cycle operation of the torque wrench as long as the advance button is pressed. (Pump can be used with or without auto cycle feature)
  • Maximum Operating Pressure bar 700
  • Maximum Operating Pressure psi 10,000
  • Shipping L T L yes
  • Weight Lbs 106
  • Compatible Products HT1503,HT1510,HT1503HR,HT1510HR,B150,BR150,BH150,BW150AW,B150B
  • Hydraulic Pump For Use With Torque Wrenches All Wrenches
  • Hydraulic Pump Maximum Flow Rate Rangesat Rated Pressure In3min 60 - 119
  • Hydraulic Pump Maximum Flow Rate Rangesat Rated Pressure Lmin 0,98 - 1,95
  • Hydraulic Pump Maximum Flowat Rated Pressure 1,0 l/min
  • Hydraulic Pump Maximum Operating Pressure Ranges Bar 700
  • Hydraulic Pump Maximum Operating Pressure Ranges Psi 10,000
  • Hydraulic Pump Motor Electrical Specification 208-240 V, 1 Ph, 50/60 Hz
  • Hydraulic Pump Motor Hertz 50/60 Hz
  • Hydraulic Pump Motor Phases 1 Ph
  • Hydraulic Pump Motor Size Hp 1.7
  • Hydraulic Pump Motor Size Kw 1,25
  • Hydraulic Pump Motor Voltage 208-240 V
  • Hydraulic Pump Output Flow Rate10000 Psi In3min 60
  • Hydraulic Pump Output Flow Rate100psi In3min 700
  • Hydraulic Pump Output Flow Rate350bar Lmin 1,2
  • Hydraulic Pump Output Flow Rate5000 Psi In3min 76
  • Hydraulic Pump Output Flow Rate50bar Lmin 8,8
  • Hydraulic Pump Output Flow Rate700 Psi In3min 535
  • Hydraulic Pump Output Flow Rate700bar Lmin 1,0
  • Hydraulic Pump Output Flow Rate7bar Lmin 11,5
  • Hydraulic Pump Pump Power Source Electric
  • Hydraulic Pump Relief Valve Adjustment Rangebar 124 - 700
  • Hydraulic Pump Reservoir Capacitycm3 8000
  • Hydraulic Pump Reservoir Capacityin3 416
  • Hydraulic Pump Sound Leveld Ba 85 - 90
  • Hydraulic Pump Usable Oilcapacity Gal 1.75
  • Hydraulic Pump Usable Oilcapacitylitres 8,0
  • Hydraulic Pump Valve Operation Solenoid
  • Hydraulic Pump pump Valve Type 4-way, 2-position
  • Hydraulic Pump weight Range Kgs 25,0 - 49,9
  • Hydraulic Pump weight Range Lbs 50 - 99.9
  • Maximum Operating Pressure bar 700
  • Shipping L T L yes
  • Compatible Products HT1503,HT1510,HT1503HR,HT1510HR,B150,BR150,BH150,BW150AW,B150B
  • Weight Kgs 48
  • Hydraulic Pump For Use With Torque Wrenches All Wrenches
  • Hydraulic Pump Maximum Flowat Rated Pressure 1,0 l/min
  • Hydraulic Pump Maximum Operating Pressure Ranges Bar 700
  • Hydraulic Pump Motor Electrical Specification 208-240 V, 1 Ph, 50/60 Hz
  • Hydraulic Pump Motor Hertz 50/60 Hz
  • Hydraulic Pump Motor Phases 1 Ph
  • Hydraulic Pump Motor Size Hp 1.7
  • Hydraulic Pump Motor Size Kw 1,25
  • Hydraulic Pump Motor Voltage 208-240 V
  • Hydraulic Pump Pump Power Source Electric
  • Hydraulic Pump Relief Valve Adjustment Rangebar 124 - 700
  • Hydraulic Pump Reservoir Capacitycm3 8000
  • Hydraulic Pump Reservoir Capacityin3 416
  • Hydraulic Pump Sound Leveld Ba 85 - 90
  • Hydraulic Pump Usable Oilcapacity Gal 1.75
  • Hydraulic Pump Usable Oilcapacitylitres 8,0
  • Hydraulic Pump Valve Operation Solenoid
  • Hydraulic Pump pump Valve Type 4-way, 2-position
  • Hydraulic Pump weight Range Kgs 25,0 - 49,9
