CYL 100 T S/A GENERAL

CYL 100 T S/A GENERAL

  • Model RC1006
  • Product Line Industrial Tools
  • Series RC

The next evolution of the legendary Enerpac RC-Series hydraulic cylinder. The driving force of the Enerpac cylinder range, the RC-TRIO is as versatile as ever. Featuring a Trio Bearing System for enhanced durability and a hybrid spring-return system for faster retraction and even greater productivity.

Enquire about this shop item here

Description

  • Unique GR2 Bearing Design, reduces wear, extending life
  • Base mounting holes enable easy fixturing
  • Designed for use in all positions
  • High strength alloy steel for durability
  • Redesigned cylinder thread protector for ease of use
  • Heavy-duty, pretensioned spring improves retraction speed
  • Baked enamel finish for increased corrosion resistance
  • CR400 coupler and dust cap included on all models
  • Plunger wiper reduces contamination, extending
  • Maximum Operating Pressure bar 700
  • Maximum Operating Pressure psi 10,000
  • Stroke in 6.63
  • Weight Lbs 130
  • Hydraulic Cylinders Cylinder Class Imperial Tons 100
  • Hydraulic Cylinders Cylinder Effective Area Advance In2 20.63
  • Hydraulic Cylinders Maximum Cylinder Capacity Advance Imperial Tons 103.1
  • Hydraulic Cylinders Maximum Cylinder Capacity Advance kn 933
  • Hydraulic Cylinders Maximum Operating Pressure Rangespsi 10,000
  • Hydraulic Cylinders Oil Capacity Advance In3 136.67
  • Hydraulic Cylinders collapsed Height A Ranges In 10.0 - 14.99
  • Hydraulic Cylinders oil Capacity Advance Cm3 2239
  • Hydraulic Cylinders return Type Single-Acting, Spring Return
  • Hydraulic Cylinders stroke Ranges In 4.5 - 6.99
  • Maximum Operating Pressure bar 700
  • Stroke mm 168
  • Weight Kgs 59,0
  • Hydraulic Cylinders Cylinder Effective Area Advance cm2 133,3
  • Hydraulic Cylinders Maximum Cylinder Capacity Advance kn 933
  • Hydraulic Cylinders Oil Capacity Advance In3 136.67
  • Hydraulic Cylinders collapsed Height A Ranges Mm 255 - 381
  • Hydraulic Cylinders oil Capacity Advance Cm3 2239
  • Hydraulic Cylinders return Type Single-Acting, Spring Return
  • Hydraulic Cylinders stroke Ranges Mm 120 - 174
  • Hydraulic Cylinders Base Mounting Holes Bolt Circle U in 5.5
  • Hydraulic Cylinders Base Mounting Holes Thread Depth Z in 1
  • Hydraulic Cylinders Base Mounting Holes Thread V 3/4"- 10 un
  • Hydraulic Cylinders Base Mounting Holes Thread V in 3/4" - 10un
  • Hydraulic Cylinders Baseto Advance Port H in 1.63
  • Hydraulic Cylinders Collapsed Height A in 14.06
  • Hydraulic Cylinders Collar Thread Length X in 1.75
  • Hydraulic Cylinders Collar Thread W in 6 7/8"- 12 UN
  • Hydraulic Cylinders Cylinder Bore Diameter E in 5.13
  • Hydraulic Cylinders Extended Height B in 20.69
  • Hydraulic Cylinders Optional Tilt Saddle Addition To Collapsed Height A1 in 0.59
  • Hydraulic Cylinders Optional Tilt Saddle Diameter J1 in 2.8
  • Hydraulic Cylinders Outside Diameter D in 7
  • Hydraulic Cylinders Plunger Diameter F in 4.13
  • Hydraulic Cylinders Saddle Diameter J in 2.8
  • Hydraulic Cylinders Saddle Maximum Tilt Angle Radius Degrees 5
  • Hydraulic Cylinders Saddle Protrusion from Plunger K in 0.11
  • Hydraulic Cylinders Base Mounting Holes Bolt Circle U mm 140
  • Hydraulic Cylinders Base Mounting Holes Thread Depth Z mm 25
  • Hydraulic Cylinders Base Mounting Holes Thread V 3/4"- 10 un
  • Hydraulic Cylinders Baseto Advance Port H mm 41
  • Hydraulic Cylinders Collapsed Height A mm 357
  • Hydraulic Cylinders Collar Thread Length X mm 44
  • Hydraulic Cylinders Collar Thread W mm 67/8"-12
  • Hydraulic Cylinders Cylinder Bore Diameter E mm 130,3
  • Hydraulic Cylinders Extended Height B mm 525
  • Hydraulic Cylinders Optional Tilt Saddle Addition To Collapsed Height A1 mm 15
  • Hydraulic Cylinders Outside Diameter D mm 177
  • Hydraulic Cylinders Plunger Diameter F mm 104,9
  • Hydraulic Cylinders Plunger Thread Length P mm —
  • Hydraulic Cylinders Saddle Diameter J1 mm 71
  • Hydraulic Cylinders Saddle Maximum Tilt Angle Radius Degrees 5
  • Hydraulic Cylinders Saddle Protrusionfrom Plunger K1 mm 2
  • Hydraulic Cylinders saddle Diameter J Mm 71
  • Hydraulic Cylinders saddle Protrusion From Plunger K Mm 2
